Monotype Unit Arrangement sheets

The sheets listed below represent a very small selection of the many produced by the Monotype Corporation in the UK. They are in the collection held by the Alembic Press, but some are very worn or poorly copied. For a given typeface, the sheet shows the unit widths and physical widths of the different point sizes of the characters in the fount. They are particularly useful when using a super caster, as composition matrices themselves do not show the unit or the width (display sizes have the width shown on the side of the matrix). The table of Unit Arrangements issued by the Monotype Corporation shows unit widths, but not physical widths, and does not show values for characters such as $,[(*?‡.

Cloister Bold (UA86) Series 271
Cloister Old Style (UA89) Series 272
Gill Bold Sans Condensed (UA316) Series 343
Gloucester Old Style (UA4) Series 99
Grotesque Bold Condensed (UA2 and UA3) Series 15
Grotesque Condensed Series 318
Italian Old Style (UA4) Series 108
Littleworth (UA371) Series 284
Univers Light Condensed (UA492) Series 686
Univers Medium Condensed (UA493) Series 690
Veronese (UA4) Series 59
or return to Monotype Lists

This page was written by David Bolton in 2025 and last updated 22 February 2025
